| Function | Common to all modelsTemp. Range · 0-65℃ · 0-65℃ · 0-65℃ |
|---|
| Function (2) | Common to all modelsTemp. Resolution Ratio · 0.1℃ · 0.1℃ · 0.1℃ |
|---|
| Function (3) | Common to all modelsTemp. Motion · High Temp:±0.5℃ Low Temp:±1℃ · High Temp:±0.5℃ Low Temp:±1℃ · High Temp:±0.5℃ Low Temp:±1℃ |
|---|
| Function (4) | Common to all modelsTemp. Uniformity · ±1.5℃ · ±1.5℃ · ±1.5℃ |
|---|
| Structure | Common to all modelsnner Chamber · Mirror Stainless Steel · Mirror Stainless Steel · Mirror Stainless Steel |
|---|
| Structure (2) | Common to all modelsOuter Shell · Cold rolling steel electrostatic spraying exterior · Cold rolling steel electrostatic spraying exterior · Cold rolling steel electrostatic spraying exterior |
|---|
| Structure (3) | Common to all modelsInsulation Layer · Polyurethane · Polyurethane · Polyurethane |
|---|
| Structure (4) | Common to all modelsHeater · Stainless steel heater · Stainless steel heater · Stainless steel heater |
|---|
| Structure (5) | Common to all modelsPower Rating · 0.8kW · 1.0kW · 1.2kW |
|---|
| Structure (6) | Common to all modelsCompressor · Air cooled hermetic compressor · Air cooled hermetic compressor · Air cooled hermetic compressor |
|---|
| Structure (7) | Common to all modelsCryogen · R134a · R134a · R134a |
|---|
| Structure (8) | Common to all modelsDefrost Structure · Automatic control intelligent defrosting · Automatic control intelligent defrosting · Automatic control intelligent defrosting |
|---|
| Structure (9) | Common to all modelsTest Hole · Inner diameter 43mm(one) · Inner diameter 43mm(one) · Inner diameter 43mm(one) |
|---|
| Structure (10) | Common to all modelsControlled External Power Supply · Outer universal socket(one), inner waterproof socket(one) · Outer universal socket(one), inner waterproof socket(one) · Outer universal socket(one), inner waterproof socket(one) |
|---|
| Control | Common to all modelsTemp. Control Mode · 30-stage LCD program · 30-stage LCD program · 30-stage LCD program |
|---|
| Control (2) | Common to all modelsTemp. Setting Mode · Touch button setting · Touch button setting · Touch button setting |
|---|
| Control (3) | Common to all modelsTemp. Display Mode · Measuring temperature:LCD upper row;Setting temperature:LCD lower row · Measuring temperature:LCD upper row;Setting temperature:LCD lower row · Measuring temperature:LCD upper row;Setting temperature:LCD lower row |
|---|
| Control (4) | Common to all modelsTimer · 0-99.9h*30 segment(with timing wait function) · 0-99.9h*30 segment(with timing wait function) · 0-99.9h*30 segment(with timing wait function) |
|---|
| Control (5) | Common to all modelsOperation Function · Program operation · Program operation · Program operation |
|---|
| Control (6) | Common to all modelsSensor · PT100 · PT100 · PT100 |
|---|
| Control (7) | Common to all modelsAdditional Function · Loop self diagnosis, sensor fault alarm · Loop self diagnosis, sensor fault alarm · Loop self diagnosis, sensor fault alarm |
|---|
| Control (8) | Common to all modelsSafety Device · Over temperature alarm · Over temperature alarm · Over temperature alarm |
|---|
| Specification | Common to all modelsInner Chamber Size(W*L*H)(mm) · 415*350*500 · 490*400*750 · 500*515*950 |
|---|
| Specification (2) | Common to all modelsExterior Size(W*L*H)(mm) · 571*591*1051 · 646*641*1301 · 656*741*1501 |
|---|
| Specification (3) | Common to all modelsPacking Size(W*L*H) (mm) · 680*676*1235 · 751*730*1490 · 761*830*1690 |
|---|
| Specification (4) | Common to all modelsVolume · 70L · 150L · 250L |
|---|
| Specification (5) | Common to all modelsLoad Per Rack · 15kg · 15kg · 15kg |
|---|
| Specification (6) | Common to all modelsShelf Number · 5 · 9 · 12 |
|---|
| Specification (7) | Common to all modelsShelf Space · 60mm · 60mm · 60mm |
|---|
| Specification (8) | Common to all modelsSupply(50/60Hz) Current Rating · AC220V/2.3A · AC220V/3.6A · AC220V/5.5A |
|---|
| Specification (9) | Common to all modelsNW/GM(kg) · 69/92 · 86/114 · 100/139 |
|---|
| Accessory | Common to all modelsShelf · 2 · 2 · 2 |
|---|
| Accessory (2) | Common to all modelsShell Frame · 4 · 4 · 4 |
|---|
| Optional Accessories | Common to all modelsshelf，RS485 port， printer， recorder， Remote Control， wireless messaging alarm. U-Disk data storage |
|---|
