Auto ELISA Processor BIOBASE4001

Name: Auto ELISA Processor BIOBASE4001
Brand: BIOBASE
SKU: BIOBASE4001

BIOBASE4001

Microplate automation, reading and washing for ELISA assays in research and laboratory diagnostics.

Made to orderPrice on request

Manufacturer: BIOBASE

Request a quote

Reply within 24 hoursValidated selection and configurationDelivery across mainland Portugal, Madeira, the Azores, and all European countries.

01 / Key features

Key features

Automated microplate processing
Assay-matched reading and washing
Configurations for different workloads

02 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

Parameter	BIOBASE4001
Sample & Reagent Unit — Sample Racks	*1216 push-pull sample rack with detection**
Sample & Reagent Unit — Sampling Channel	4 channels
Sample & Reagent Unit — Liquid Level Detection	Air pressure level detection, clot detection function
Sample & Reagent Unit — Tip	1000μl, 5 tip racks
Sample & Reagent Unit — Pipetting	5 μ l~1000 μ l
Sample & Reagent Unit — Pipetting Precision	100μl: CV≤1.0%, Accuracy≤2.0% 1000μl: CV≤0.5%, Accuracy≤1.0%
Sample & Reagent Unit — Reagent Position	6 reagent racks, reagent tanks with detection
Washing Unit — Washer	2 units
Washing Unit — Washing Head	16-channel(32-pin), double row cleaning, hanging installation, with leakage recovery
Washing Unit — Injection Uniformity	CV<1.5%
Washing Unit — Washing Residual	<1μl
Readi ng Unit	Reading Channels · 8 independent photometric channels, mono and dichromatic reading
Readi ng Unit (2)	Linear Range · 0.000~3.000Abs
Readi ng Unit (3)	Repeatability · CV≤1.0%
Readi ng Unit (4)	Stability · ≤±0.003Abs
Readi ng Unit (5)	Optical Filters · 4 standard filters(405, 450, 492, 630nm) Total 10 filters positions
Readi ng Unit (6)	Reading Accuracy · ≤±0.02Abs from 0.0 to 1.0OD ≤±0.03Abs from 1.0 to 2.0OD
Readi ng Unit (7)	Sensitivity · ≥0.01mg/L
Readi ng Unit (8)	Channel Difference · ≤0.02Abs
Incubation Unit — Incubators	12 shaking incubators
Incubation Unit — Cover Positions	2(12 covers)
Incubation Unit — Heating Method	Dry heating with cover
Incubation Unit — Shaking Function	Horizontal circular oscillation, 1~3 levels adjustable, amplitude 2.5mm
Incubation Unit — Temperature Range	RT to 60 °C
Incubation Unit — Temperature Uniformity	0. 5 ℃
Incubation Unit — Temperature Fluctuation	±0. 5 ℃
Data Management — Software	Above Windows 7 system
Data Management — LIS System	Bi-direction, support HL7 protocol
Data Management — Results	Absorbance and results reviewable by software
Data Management — Printer	External optional
Data Management — Built-in Scanner	Optional
Other Function — Biosafety Protection	Optional(Negative pressure working zone, HEPA filter)
Other Function — Disinfection	UV lamp
Other Function — Lighting	LED
Other Function — IAP Function	Firmware can be upgraded online at any time
Working Condition — Power Supply	AC220V±10%, 50/60Hz(Standard); 110V±10%, 60Hz(Optional)
Working Condition — Temperature	10~40℃
Working Condition — Humidity	30~80%
Size&Weight — External Size (WDH)	*17751901683mm*
Size&Weight — Net Weight	445kg
Size&Weight — Package Size(WDH)mm	*Machine: 19459501150 Base Stand: 1945950995 Accessories: 1370930530*
Size&Weight — Gross Weight(kg)	Machine: 364.5 Base Stand: 208.5 Accessories : 9 7
